Produktbeschreibung

The T version of the boxer range completes perfectly the constructiove program covering the whole power array of high pressure discharge lamps that goes from 35 to 150W in the metal halide versions with quartz or ceramic burner and white solar light sodiu

m White Son. A feature peculiar to boxer models is the great luminous efficiency, that allows considerable energy savings.

The presence of a die-cast counterflange inside the fixture allows the quick insertion of a shielding grid or coloured filt

ers.
The use of electronic ballasts allows the steady power operation of the lamp also in case of mains variations.
One can thus obtain a greater luminous flux stability and lamp life span.

A rich array of accessories makes the program qu

ite adaptable and able to satisfy any installation need:

D30T/VS shielding visor
D30T/GP shielding grid
D30T/V coloured glass
D30T/PZ ground spike

Eigenschaften
Bestückung

B30T boxer T/MH:
1 x HST-CRI max 35W - G12 - 3400 lumen
or 1 x HST-CRI max 70W - G12 - 5500/6600 lumen
or 1 x HST-CRI max 150W - G12 - 12500/14000 lumen

B30T boxer T/SW:
1 x 50W - GX12 - 2300 lumen
or 1 x 100W - GX12 - 4900 lu

men

Form Diffusor/Reflektorrund
Breite200 mm
Höhe345 mm
Tiefe163 mm
Schutzart (nach DIN 40050)IP66 Vollständiger Schutz/Staubdicht/Gegen Überflutung
SchutzklasseKlasse I (Schutzerdung)
Brand­schutz­klassenF
Alle boxer Produkte

Hersteller:
Castaldi Lighting, Italien
