Mile Wandleuchte

Stylepark-ID:04.2104.11251
Kategorien: AußenleuchtenAufbauleuchtenWandaufbauleuchten
Produktbeschreibung

«The focus of the Mile project is to reduce the size of the object while obtaining the best optical performance possible. This work involves different aspects: minimization, high performance, and the perceived quality of a ‘perfect object’, where all outdoor surfaces are on the same plane. The final result was achieved through hard work to optimize the unit’s parts.»
Antonio Citterio.

A complete programme of professional outdoor luminaires with a rigorous and minimal design, ideal for projects such as urban spaces and public landscapes. The wall-mounted collection is completed with a bollard version, available with a sophisticated single or dual directional lighting emission.

Mile features a very subtle and compact profile so as not to impact on the environment. The collection offers a complete programme of optics for complex projects, including a deep asymmetric emission for lighting paths or open spaces; an indirect asymmetric version for ceilings, corridors or galleries; and a special grazing light effect to reveal volumes and vertical surfaces.

Finishes: white, grey, anthracite, black, deep brown, forest green, primer (only for the wall model)

Eigenschaften
Bestückung

Lighting source: Mid Power LED

Mile Wall 1 Asymmetric Up / Down - Mile Wall 1 Washer Up / Down
4,5W - 431 lm ≠ *FIXT 256 lm - 2700K/CRI 80 - 220-240V
4,5W - 448 lm ≠ *FIXT 266 lm - 3000K/CRI 80 - 220-240V
4,5W - 465 lm ≠ *FIXT 277 lm - 4000K/CRI 80 - 220-240V

Mile Wall 1 Asymmetric Up & Down
7,5W - 2x431 lm ≠ *FIXT 2x256 lm - 2700K/CRI 80 - 220-240V
7,5W - 2x448 lm ≠ *FIXT 2x266 lm - 3000K/CRI 80 - 220-240V
7,5W - 2x465 lm ≠ *FIXT 2x277 lm - 4000K/CRI 80 - 220-240V

Mile Wall 1 Washer Up & Down
7,5W - 2x431 lm ≠ *FIXT 2x240 lm - 2700K/CRI 80 - 220-240V
7,5W - 2x448 lm ≠ *FIXT 2x250 lm - 3000K/CRI 80 - 220-240V
7,5W - 2x465 lm ≠ *FIXT 2x260 lm - 4000K/CRI 80 - 220-240V

Mile Wall 1 Washer Down + Asymmetric Up
7,5W - 2x431 lm ≠ FIXT 256+240 lm - 2700K/CRI 80 - 220-240V
7,5W - 2x448 lm ≠ FIXT 266+250 lm - 3000K/CRI 80 - 220-240V
7,5W - 2x465 lm ≠ FIXT 277+260 lm - 4000K/CRI 80 - 220-240V

Mile Wall 2 Asymmetric Up - Mile Wall 2 Asymmetric Down
7,5W - 846 lm ≠ *FIXT 503 lm - 2700K/CRI 80 - 220-240V
7,5W - 879 lm ≠ *FIXT 523 lm - 3000K/CRI 80 - 220-240V
7,5W - 913 lm ≠ *FIXT 543 lm - 4000K/CRI 80 - 220-240V

Mile Wall 2 Washer Up - Mile Wall 2 Washer Down
7,5W - 846 lm ≠ *FIXT 472 lm - 2700K/CRI 80 - 220-240V
7,5W - 879 lm ≠ *FIXT 491 lm - 3000K/CRI 80 - 220-240V
7,5W - 913 lm ≠ *FIXT 510 lm - 4000K/CRI 80 - 220-240V

Mile Wall 2 Asymmetric Up & Down
13,5W - 2x846 lm ≠ FIXT 2x503 lm - 2700K/CRI 80 - 220-240V
13,5W - 2x879 lm ≠ FIXT 2x523 lm - 3000K/CRI 80 - 220-240V
13,5W - 2x913 lm ≠ FIXT 2x543 lm - 4000K/CRI 80 - 220-240V

Mile Wall 2 Washer Up & Down
13,5W - 2x846 lm ≠ FIXT 2x472 lm - 2700K/CRI 80 - 220-240V
13,5W - 2x879 lm ≠ FIXT 2x491 lm - 3000K/CRI 80 - 220-240V
13,5W - 2x913 lm ≠ FIXT 2x510 lm - 4000K/CRI 80 - 220-240V

Mile Wall 2 Washer Down + Asymmetric Up
13,5W - 2x846 lm ≠ FIXT 503+472 lm - 2700K/CRI 80 - 220-240V
13,5W - 2x879 lm ≠ FIXT 523+491 lm - 3000K/CRI 80 - 220-240V
13,5W - 2x913 lm ≠ FIXT 543+510 lm - 4000K/CRI 80 - 220-240V

MaterialMetall
Alle Mile Produkte


Hersteller:
FLOS, Italien

Design:
Antonio Citterio
2020

Kataloganfrage

Zum Anfragen eines Katalogs, füllen Sie bitte unser Formular aus.

Nähere Informationen finden Sie in unserer Datenschutzerklärung.

PDF-Katalog

Zum Anfragen eines PDF-Katalogs, füllen Sie bitte unser Formular aus.

Nähere Informationen finden Sie in unserer Datenschutzerklärung.

Angebotsanfrage

Zum Anfragen eines Angebots, füllen Sie bitte unser Formular aus.

Nähere Informationen finden Sie in unserer Datenschutzerklärung.
Downloads

von FLOS

DateiformatDateinameGrößeDownload
PDFOUTDOOR-NEWS-CATALOGUE-2020-DE_EN.pdf27,381 MB
