Prologe 145 in-Dolma/in-Line single

Stylepark-ID:04.1600.10303
Categories: Interior lightingBuilt-in lightsCeiling built-in lights
Product description

kreon prologe reflects thoroughly kreon’s principles in lighting: quality, design and architectural integration. kreon prologe is a basic lighting concepts that, in a modular system, offers compositions of enormous flexibility for highly personalised light scenographies.

kreon prologe wants to create functional light through the discreet presence of simple architectural volumes and adds fixed and directional LED lightsources in a surface mounted box. kreon prologe in-line and kreon prologe in-dolma give light mass, depth and form. Recessed in a ceiling, it sculpts architecture. Openings are made in the plastered surfaces using prefabricated anodised aluminium profiles that support the kreon prologe elements. The profiles, measure-made, are pre-cabled and realized according to your lighting design. The standard fitting is made of black or white powder coated steel.

Specifications
Fittings

GY6.35, G53, G8.5, GX8.5, GX24-Q3/4

Lamp types/max. output:
QT12-ax: 75W
QR-LP111: 75W
HIT-TC: 35W/70W
HIR-CE111: 35W/70W

Diffuser/reflector shapecircular
Length140 mm
Width140 mm
Height100 mm
Installation width170 mm
Installation depth1900 mm
Form of protection (DIN 40050)IP20 protection against: solids > 12 mm
Safety classclass I (protective earthing)
Materialaluminium
Colorsshades of grey
silver
white
black
All Prologe Products


Manufacturer:
Kreon, Belgium
