LED-Linargo surface-mounted luminaire
| Stylepark-ID: | 04.8934.00017 |
|---|---|
| Categories: | Interior lighting ›Surface mounted lights ›Ceiling mounted lights |
| Interior lighting ›Built-in lights ›Ceiling built-in lights |
Product description
A very simplistic design mated with the exact level of brightness. LED Linargo is available as a recessed luminaire, which thanks to its modular design can be stringed together to form a continuous light band, and also as a pendant luminaire. Ideal for corridors, offices or above counter tops.
- For hotels, offices, showrooms, laboratories and production sites
- Suitable for emergency lighting systems acc. to EN 50172
- Narrow light colour tolerances
- Glare suppression by satinised PMMA sheet
- Perfect homogeneous light spread, even if several LED modules are stringed together
- Clamps for quick and easy wiring from one LED module to the next
- The light colours are dimmable and controllable using DMX
Specifications
| Length | 1690 mm |
|---|---|
| Width | 38 mm |
| Height | 80 mm |
| Emission class | A |
| Light regulation | stepless dimmer |
| Stand/ mounting | with pendant hanging |
| Diffuser/reflector shape | rectangular |
| Inspection seal /certification | CE |
| Form of protection (DIN 40050) | IP40 protection against: solids >1mm |
| Safety class | class III (protective low voltage) |
| Material | aluminium |
| Colors | black white silver |
