Ray-T

Stylepark-ID:04.2104.11153
Categories: Interior lightingTable lamps
Product description

Table lamp providing diffused lighting. Steel tube (10 mm diam.) structure, welded, brushed and chrome-plated. Diffuser support disk in die-cast, polished and chrome-plated Zamak alloy. White injection-molded PA6 (nylon) lamp cover. Injection-molded PC (p

olycarbonate) inner diffuser in 3% opal color. Transparent injection-molded elastic PVC (polyvinylchloride) feet. Lathe-shaped aluminum diffusers, painted white on the inside, and shiny white or black on the outside or gray-colored, blown and overlaid gla

ss with glossy external finish. On the cable there is the electronic Muvis dimmer which allows the regulation of light brightness with a dial and the radio-frequency connection with the Flos CuboTM.

Specifications
Fittings
Emission classC - E
Light regulationstepless dimmer
Stand/ mountingwith legs
Diffuser/reflector shapecircular
Inspection seal /certificationENEC
Height674 mm
Diameter360 mm
Weight545 kg
Form of protection (DIN 40050)IP20 protection against: solids > 12 mm
Safety classclass II (protective isolation)
Materialaluminium
glass
steel
Colorswhite
shades of grey
black
All Ray Products


Manufacturer:
Flos, Italy

Design:
Rodolfo Dordoni
2007
